HENAN HOBE METAL MATERIALS CO.,LTD.
Professional aluminium discs circles producer!
Sales & Support:
 |
| Place of Origin: | China |
| Brand Name: | Hobe |
| Certification: | ISO/ROHS/SGS |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Pallet or Wooden Case |
| Delivery Time: | 10-25 days |
| Supply Ability: | 1000Ton per Month |
| Material: | AL | Alloy: | 1100 Quarter Hard |
|---|---|---|---|
| Thickness: | 2.0mm Etc | Diameter: | 550mm And Etc |
| Surface: | Mill Finish | Application: | Route Marker Signs |
| High Light: | aluminum circle sheet,aluminium round plate |
||
| 1100 Chemistry composition | |||||||||
| Element | Si | Fe | Cu | Mn | Mg | Cr | Ti | Zn | Al |
| Standard Value | Si + Fe =0.95 | 0.05-0.2 | 0.05 | ---- | ---- | ---- | 0.01 | 99.00 | |
Description:
1. Alloy type :
1050 1060 1070 3003 3004 3105 5052
2. Temper:
O,H26,H24,H22,H18
3. Thickness Range:
0.35mm~5mm
4. Diameter Range:
130~1300mm
5. Surface Finish
Bright & smooth surface, without flow lines, slightly oiled to avoid White rusting.
6. Quality of material:
Totally free from defects like White Rust, Oil Patches, Roll Marks, Edge Damage, Camber, Dents, Holes, Break Lines, Scratches and free from coil set.
Aluminum disc Surface Finish: Bright & smooth surface, without flow lines, slightly oiled to avoid White
rusting. Smooth, Brightly, No Zone of Fracture, No Scratched, No oil Sludge
Quality of Material: Totally free from defects like White Rust, Oil Patches, Roll Marks,
Edge Damage, Camber, Dents, Holes, Break Lines, Scratches and free from coil set.
We enjoy a good reputation among our customers for our aluminum circle with high quality and
competitive price; win high appreciation from our clients with the excellent workman-ship and
professional ability. The quality matches with ISO 9001 quality management system.
It is equipped with 5 hot tandem rolling line, 4 cold mill production lines, 4 annealing surface
machines and complete finishing equipment.
Our motto and mission is to offer best service for our customer with Heart and Soul.
Producing Procedure from Aluminum Ingot to Aluminum Circles:
Specifications:
| Temper | Thickness(mm) | Tensile Strength | Elongation(%) | Standard |
| O | 0.4-6.0 | 60-100 | ≥ 20 | GB/T3190-1996 |
| H12 | 0.5-6.0 | 70-120 | ≥ 4 | |
| H14 | 0.5-6.0 | 85-120 | ≥ 2 |
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ca | V | Ti | Other | Min Al |
| 1050 | 0.24 | 0.40 | 0.05 | 0.05 | 0.06 | / | / | 0.05 | / | 0.05 | 0.03 | 0.03 | 99.5 |
| 1060 | 0.25 | 0.36 | 0.05 | 0.03 | 0.02 | / | / | 0.05 | / | 0.05 | 0.03 | 0.03 | 99.6 |
| 1070 | 0.20 | 0.25 | 0.04 | 0.03 | 0.03 | / | / | 0.05 | / | 0.05 | 0.03 | 0.03 | 99.7 |
| 1100 | 0.95 | 0.94 | 0.05-0.2 | 0.06 | / | / | / | / | / | / | / | 0.05 | 99.0 |
| 3003 | 0.61 | 0.70 | 0.5-0.2 | 1.0-1.5 | / | / | / | / | / | / | / | 0.14 | 96.75 |
| 5052 | 0.40 | 0.40 | 0.10 | 0.11 | 2.2-2.8 | 0.15-0.35 | / | 0.10 | / | / | / | 0.14 | Remain |
Applications:
1. Deeply-drawing for making kitchenware
2. Cookware
3. Cooking utensil
4. Non-stick pans/pots
5. Traffic sign
6. Reflector
7. Cold extrusion
Competitive Advantage:
1. Wide range of selection on circle’s size including customized shape and size.
2. Excellent surface quality for lighting reflectors.
3. Excellent deep drawing and spanning quality.
4. We provide heavy guage circles with thickness up to 6mm thick which is deal for cookware.
5. Anodized quality and deep drawing quality which is suitable for cookware as well.
6. Well- protected packing.
