Place of Origin: | China |
Brand Name: | Hobe |
Certification: | CO |
Model Number: | 1050 1060 1070 1100 |
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiation |
Packaging Details: | Pallet or Wooden Case |
Delivery Time: | 15-25days |
Supply Ability: | 1500Ton per Month |
Product: | Aluminum Sheet Circles | Alloy: | 3003 |
---|---|---|---|
Size: | 11.5 Inch X 3mm | Temper: | HO |
Technology: | DC | Application: | Pressure Cooker |
Highlight: | aluminium circles,aluminum disks |
Quick Detal:
Product name | alumimun sheet Circle |
Material | 3003 |
Tempers | O |
Application | Pressure Cooker |
Standard | China Nation Standard GB 3880-2006, ASTM, EN |
Description:
Aluminum alloy circle is widely used in cookware, Transport road sign boards, Lighting cover.
Aluminum is the most common material for cookware, as it is an excellent conductor of heat and is inexpensive compared to copper or stainless steel.
Although features such as the lid, handle and finish are important, thickness is the key element of quality. The thicker the pan, the better the heat dispersion, reduces the chance of "hot spots" occurring. Remember, since an aluminum pan is all aluminum, heat spreads evenly over the total surface, including side walls. Traditional stainless steel pans spread heat evenly only on the copper or aluminum base.
Aluminium circle/Aluminum discs Quality policy
The quality policy of Haomei is to establish, implement, and maintain an effective assurance system based on ISO 9001 with the full participation of all employees in the process of continuous quality improvement and quality assurance practices resulting in total customer satisfaction. By encouraging open communication, we are dedicated to achieve true and sincere partnership with both internal and external customers resulting in total customer satisfaction.
Continuous Quality Improvement
The purpose of our quality system is to continuously improve the quality of our products, our services, and productivity in order to achieve internal and external customer satisfaction.
Qualify Control:
The central laboratory is equipped with the device which made by the world's top manufacturer.
They can carry out the test such as :the product composition analysis, mechanical performance analysis, metallographic analysis, environmental simulation, heat test, testing analysis, corrosion analysis, project.
Our company had built the quality supervision department and Aluminum lab to control the quality of production which will export the other countries.
Surface Grade:
Be free from Oil Stain, Dent, Inclusion, Scratches, Stain, Oxide Discoloration, Breaks, Corrosion, Roll Marks, Dirt Streaks and other defect which will interfere with use.
Surface without black line, clean cut, periodic stain, roller printing defects, such as other gko internal Control standards.
Features
Wide range of selection on circles' size including customized shape and size;
Excellent deep drawing and spinning quality;
Bright surface, no scratch
Chemical composition
Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al | |
1060 | 0.250 | 0.350 | 0.050 | 0.030 | 0.030.- | - | 0.050 | 0.030 | 99.6 |
1070 | 0.200 | 0.250 | 0.040 | 0.030 | 0.030 | - | 0.040 | 0.030 | 99.7 |
1100 | Si+Fe:0.95 | 0.05-0.2 | 0.050 | - | - | 0.100 | - | 99.0 | |
3003 | 0.600 | 0.700 | 0.05-0.20 | 1.0-1.5 | - | - | 0.100 | - | remains |
3105 | 0.600 | 0.700 | 0.300 | 0.30-0.8 | 0.20-0.8 | 0.200 | 0.400 | 0.100 | remains |
5052 | 0.250 | 0.400 | 0.100 | 0.100 | 2.2-2.8 | 0.15-0.35 | 0.100 | - | remains |
5154 | 0.250 | 0.400 | 0.100 | 0.100 | 3.1-3.9 | 0.15-0.35 | 0.200 | 0.200 | remains |
5754 | 0.400 | 0.400 | 0.100 | 0.500 | 2.6-3.6 | 0.300 | 0.200 | 0.150 | remains |
5182 | 0.200 | 0.350 | 0.150 | 0.20-0.50 | 4.0-5.0 | 0.100 | 0.250 | 0.100 | remains |
6061 | 0.3-0.7 | 0.500 | 0.100 | 0.030 | 0.35-0.8 | 0.030 | 0.100 | - | remains |
8011 | 0.5-0.9 | 0.6-1.0 | 0.100 | 0.200 | 0.050 | 0.050 | 0.100 | 0.080 | remains |
8079 | 0.200 | 0.300 | 1.0-1.6 | 0.100 | 0.6-1.3 | 0.100 | 0.250 | 0.100 | remains |
Specification
pecification | aluminium sheet circle | ||||||||||||
Alloy: 1050, 1060,1070, 1100, 1200,3003 ,6061 etc. | |||||||||||||
Temper: TO, H12, H22, H14, H24, H26, H18 etc. | |||||||||||||
Thickness: 0.2-200mm | |||||||||||||
Width: Up to 1800mm | |||||||||||||
Length: Up to 6000mm | |||||||||||||
Surface treatment: mill finished, anodized, embossed, PVC coated | |||||||||||||
Feature | Price is much more competitive than that of other series. | ||||||||||||
Satisfy regular industrial process of stamping, drawing with good elongation, tensile strength and high formability. | |||||||||||||
Great plasticity, corrosion resistance, electrical conductiviy and termal conductivity. | |||||||||||||
Easy to be welded. | |||||||||||||
Easy to be pressure processed, extended and bent. | |||||||||||||
Application | Sign board, Advertising board, Building decoration, Car body, Cooking utensil, Lamp holder, Fan leaf, Electrical part, Chemical instrument, Machined part, Deep-drawn or spinned part, Welded part, Heat exchanger, Clock surface, Decotation, Reflective instrument etc. | ||||||||||||
Alloy | Chemical Component %≤ | ||||||||||||
Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | others | Al | |||
single | total | ||||||||||||
1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | 0.05 | 0.03 | 0.03 | 99.50 | ||||
1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | 0.05 | 0.03 | 0.03 | 99.60 | ||||
1100 | 0.95 | 0.05-0.2 | 0.05 | 0.1 | 0.05 | 0.15 | 99.00 | ||||||
1200 | 1.00 | 0.05 | 0.05 | 0.1 | 0.05 | 0.05 | 0.15 | 99.00 |
Application of cookware Aluminium circle:
aluminium circle for pot making,
aluminium disk for pot,
Deep drawing cookware,
spinning cookware
aluminium circle,
pot circle,
cooking utensils,
cooker, pan,pot,boiler,
cookware making
road sign and traffic sign, and signal plate
FAQ
Q 1. What is the payment term of your company?
A: TT, L/C for large order; Western union, is also acceptable for small order.
Q 2. Can you guarantee the quality is the same as that of sample when mass production?
A: Sure. Preshipment sample can be sent, or any kind of inspection is acceptable.
Q 3. What certificate you have?
A: SGS, CIQ or other test report can be provided if clients' require.
Q 4. How long is the sample making time? And how can we get?
A: Within 7 days for lab making. Free sample within 1kg can be provided on customer's international express courier.
