HENAN HOBE METAL MATERIALS CO.,LTD.
Professional aluminium discs circles producer!
Sales & Support:

|
| Place of Origin: | China |
| Brand Name: | Hobe |
| Certification: | CO |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Pallet or Wooden Case |
| Delivery Time: | 15-21 days |
| Payment Terms: | L/C, T/T, D/P, Western Union，Cash |
| Supply Ability: | 1500Ton per Month |
| Material: | Aluminium Alloy | Alloy: | 1235 |
|---|---|---|---|
| Thickness: | 15 Gauge, 10 Gauge | Diameter: | 6 To 42 Inch. |
| Surface: | Mill Finish | Application: | Catering Tray |
| High Light: | round aluminum discs,aluminum disks |
||
Quick Detal:
Used in manufacturing of:
Utensils.
Deep Aluminium items.
Specifications:
Available in 6 to 42 Inch.
Thickness available in 6 to 23 Gauge.
Description:
We are efficient in providing quality Aluminium Circle to the clients.These circles are developed using high quality raw material and advance technical processes.
Product Details:
Corrosion resistance
Fine finished polish
Perfect dimension
High durability
High strength
We manufacture and supply Aluminium Circle in Zhengzhou, Henan, China to our customers. These are offered in various thickness, tamper, length, width and dimensions to meet specific needs of the clients. Best quality aluminium is used in the manufacturing process that have define characteristics of chemical composition.
We are one of the best efficient manufacturer and supplier of an exceptional range of Aluminium Circles. These are made using top grade aluminium to make sure durability. We offered range is well-known to provide maximum performance even in long run. Manufactured using advanced technique of production, we provide an special range of Aluminium Circles. These are highly recognized for rust resistance which boosts the service life of our products.
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | - | 0.05 | 99.6 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | - | - | 0.04 | 99.7 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.05 | - | - | 0.1 | - | 99 | |
| 1200 | Si+Fe:1.00 | 0.05 | 0.05 | - | - | 0.1 | 0.05 | 99 | |
| 1235 | Si+Fe:0.65 | 0.05 | 0.05 | 0.05 | - | 0.1 | 0.06 | 99.35 | |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | remains |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | - | - | 0.25 | remains |
| 3005 | 0.6 | 0.7 | 0.25 | 1.0-1.5 | 0.20-0.6 | 0.1 | - | 0.25 | remains |
| 3105 | 0.6 | 0.7 | 0.3 | 0.30-0.8 | 0.20-0.8 | 0.2 | - | 0.4 | remains |
| 3A21 | 0.6 | 0.7 | 0.2 | 1.0-1.6 | 0.05 | - | - | 0.1 | remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | - | 0.25 | remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.40-1.0 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | remains |
| 5154 | 0.25 | 0.4 | 0.1 | 0.1 | 3.1-3.9 | 0.15-0.35 | - | 0.2 | remains |
| 5182 | 0.2 | 0.35 | 0.15 | 0.20-0.50 | 4.0-5.0 | 0.1 | - | 0.25 | remains |
| 5251 | 0.4 | 0.5 | 0.15 | 0.1-0.5 | 1.7-2.4 | 0.15 | - | 0.15 | remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | remains |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | remains |
| 6063 | 0.20-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | - | 0.1 | remains |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.40-1.0 | 0.6-1.2 | 0.25 | - | 0.2 | remains |
| 6A02 | 0.50-1.2 | 0.5 | 0.20-0.6 | Or Cr0.15-0.35 | 0.45-0.9 | - | - | 0.2 | remains |
| 8011 | 0.50-0.9 | 0.6-1.0 | 0.1 | 0.2 | 0.05 | 0.05 | - | 0.1 | remains |
| Temper | |
| F | processing state |
| H | strain hardening state |
| O | annealing |
| T | heat treatment state |
| H112 | pure state of strain hardening, adjustment has been made to degree of strain hardening and annealing |
| T4 | solid solution treatment and natural efficiency to achieve sufficient stability condition |
| T5 | artificial aging condition of the reentry after high temperature thermal cooling |
| T6 | artificial aging state after solid solution treatment |
Manufacturing Process
Aluminum Ingot/Master Alloys --- Aluminum Melting Furnace - --- Aluminum Slab --- Hot Rolling (Direct Cast)
Or Cold Rolling (Cold Cast) – Punching – Annealing Furnace -- Final Inspection – Packing --- Delivery
Cold Rolling Aluminum Circles are widely used in furnitures like tables. But most aluminum circles clients requested are Deep Drawing Quality Aluminum Circle. These aluminum circle are widely used in kitchenware, cookware, reflector-light etc.
Features
Wide range of selection on circles' size including customized shape and size;
Excellent deep drawing and spinning quality;
Bright surface, no scratch
Specifications:
| Item | Aluminium Circle plate |
| Standard | ASTM AISI, SUS, EN, JIS, DIN, GB ASME |
|
Other Material |
1060, 1050, 1070, 1100, 3003, 3004, 5052, 5652, 5154, 5254, 5454, 5083, 5086, 5056, 5456, 2024, 2014, 6061, 6063. etc |
| Surface | Hairline ,oxidation ,mirror ,embossed ,etc |
| Thickness | 0.15mm-2.0mm ,2.0mm-6mm ,6mm-25mm |
| Width | 500mm,1000mm,220mm, 250mm,1500mm,or be required |
| Length |
1000mm,2000mm,2440mm,3000mm,3048mm,6000mm, or as required |
|
Application |
1. Lighting 2, solar reflector plate 3, architectural appearance 4, interior decoration: ceiling, metope, furniture, cabinets and so on 5 June, 6. elevator 7, plate, nameplate, bags 8, automotive interior and exterior decoration 9. Interior decoration: such as photo frame 10, household appliances, refrigerator, microwave oven, audio equipment, etc. 11. Aerospace and military aspects, such as China's current large aircraft, the shenzhou spacecraft series, satellite, etc. 12, machinery parts processing, mold manufacturing 13, chemical/insulation pipeline coating |
| Payment terms | T/T, L/C, and Western Union |
| Price terms | FOB CIF CFR CNF etc |
| Package | Export standard package:bundled wooden box or be required; The inner size of container is below: (1) 20footGP:5.8m(length)x2.13m(width)x2.18m(high)about24-26 CBM (2) 40footGP:11.8m(length)x2.13m(width)x2.72m(high)about68 CBM |
| Delivery time | Normally according to the order quantity |
Applications:
CC quality
Recessed lighting
High bay industrial lighting
Stress lighting
Traffic light reflectors
Sports lighting.
DC quality
Restaurant cookware, Rice cooker, Pressure cooker, Pan, Bakeware, Bread Makers, Road sign, Traffic sign, Auto parts, Appliance.
Competitive Advantage:
1. Wide range of selection on circle’s size including customized shape and size.
2. Excellent surface quality for lighting reflectors.
3. Excellent deep drawing and spanning quality.
4. We provide heavy guage circles with thickness up to 6mm thick which is deal for cookware.
5. Anodized quality and deep drawing quality which is suitable for cookware as well.
6. Well- protected packing.
