Place of Origin: | China |
Brand Name: | Hobe |
Certification: | CO |
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiation |
Packaging Details: | Pallet or Wooden Case |
Delivery Time: | 7-35 days |
Supply Ability: | 1000Ton per Month |
Material: | Aluminium | Alloy: | 1000series, 3000series |
---|---|---|---|
Thickness: | 0.72mm, 1.25mm And Etc | Diameter: | 50mm To 1600mm |
Surface: | Mill Finish, Annealed | Usage: | Utensils |
Highlight: | aluminum disk blanks,blank aluminum discs |
Quick Detal:
1. Alloy: 1000 / 3000 Series
2. Temper: O, H12, H14
3. Thickness: 0.3mm ~ 5.5mm
4. Diameter: 100mm - 1250mm
5. Type: Disk, Round sheet, Circle, Disc and Etc
6. Min order: 500kgs each size
7. Payment TT or Irrevocable LC at sight
Description:
As a main supplier of Aluminum Circle, we are manufactured from pure aluminum and are used in cookware and engineering, such as cooking wares, lighting purpose, cooker, frypan, pots, kettles, reflector of the light, etc...Deep drawing and hard anodizing quality Aluminum Circle Sheet can be supplied. Our Aluminum Circle is RoHS and REACH compliance and uses well-protected packing. Our circles are excellent material for producing cookware, utensil, pots, pans and kettles.
Hobe Aluminum is a professional aluminum manufacturer, mainly produces series-1, series-3, series-5, series-6 and series-8 pure aluminum and aluminum alloy plate/sheet/coil/strip/discs, etc, such as hot -rolled thick plate for molding, aluminum sheet for metal cap, Aluminium Round for cookware, aluminum strip for transformers, aluminum tread/checkered plate, aluminum drilling entry for PCB, aluminum household foil, and so on. We have been exporting Aluminum Circle to US, UK, Italy, Germany, Netherlands, Bulgaria, Brazil, Chile, Thailand, Vietnam, Ghana, etc.
Cold Rolling/ Hot Rolling Aluminum Circles are widely used in furnitures like tables. But most aluminum circles clients requested are Deep Drawing Quality Aluminum Circle. These aluminum circle are widely
used in kitchenware, cookware, reflector-light etc.
Aluminum Circle Features:
1. Wide range of selection on circles' size including customized shape and size;
2. Excellent deep drawing and spinning quality;
3. RoHS and REACH compliance.
1100 1050 3003 5052 hot rolled cookware aluminum discs ,THICKNESS IS THE KEY TO QUALITY
Aluminum is the most common material for cookware, as it is an excellent conductor of heat and is inexpensive compared to copper or stainless steel. Although features such as the lid, handle and finish are important, thickness is the key element of quality. The thicker the pan, the better the heat dispersion, which reduces the chance of "hot spots" occurring. Remember, since an aluminum pan is all aluminum, heat spreads evenly over the total surface, including the side walls. Traditional stainless steel pans spread heat evenly only on the copper or aluminum base.
1100 1050 3003 5052 hot rolled cookware aluminum discs —THE GOOD AND THE BAD
When it comes to quality in plain aluminum pans, it is a story of the "very good" or "very bad." Tour your favourite restaurant's kitchen and you will see primarily plain aluminum pans, especially huge stockpots. Why? Performance. Thick gauge pans needed for rugged commercial use are less expensive to manufacture in aluminum than stainless steel or copper. However, due to aluminum's low cost, it is also perfect for the "very bad" thin-gauge cookware. Most stores do not carry plain aluminum pans.
The is DC and CC quality for the cookware aluminium discs, but the DC quality is better . If you you DC quality can produce perfect smooth cookingware,can use long time.
Specifications:
Item | Alloy | Temper | Thickness (mm) | Diameter (mm) |
Aluminum Circle | 1050 | H0/H14/H18/H24 /H22 | 0.5-6.0mm | 180-1200mm |
1060 | ||||
1070 | ||||
1100 | ||||
3003 | ||||
5052 | ||||
5754 | ||||
5085 | ||||
6061 | ||||
8011 |
Tolerance
Dimensions | ||
Parameter | Range | Tolerance |
Thickness for circles (mm) | 0.71 _ 6.35 | for 0.71 to 1.4 +/-0.08 |
for 1.41 to 2.5 +0.1, -0.13 | ||
for 2.51 to 4.0 +/-0.13 | ||
for 4.01 to 5.00 +/-0.15 | ||
for 5.01 to 6.35 +/-0.20 | ||
Thickness for ovals (mm) | 1.75 _ 3.00 | for 1.75 to 2.5 +0.1, -0.13 |
for 2.51 to 3.00 +/-0.13 | ||
Diameter (mm) | 102 _ 1250 | (a) sheared circles +2, -0 |
(b) punched circles +0.5, -0 | ||
Earing | < 5% for ' O' temper < 9% for H12, H14, H16, H18 |
Diameter List
≧20 | ≧140 | ≧170 | ≧200 | ≧250 | ≧300 | ≧400 | ≧500 | ≧600 | ≧700 | ≧800 |
20 | 140 | 170 | 200 | 250 | 300 | 400 | 500 | 600 | 700 | 800 |
25 | 145 | 175 | 205 | 252 | 305 | 405 | 505 | 605 | 705 | 805 |
95 | 150 | 180 | 210 | 254 | 310 | 410 | 510 | 610 | 710 | 810 |
100 | 155 | 185 | 215 | 255 | 315 | 415 | 515 | 615 | 715 | 815 |
105 | 160 | 190 | 220 | 258 | 320 | 420 | 520 | 620 | 720 | 820 |
110 | 165 | 195 | 225 | 260 | 325 | 425 | 525 | 625 | 725 | 825 |
115 | 230 | 330 | 430 | 530 | 630 | 730 | 830 | |||
120 | 235 | 335 | 435 | 535 | 635 | 735 | 835 | |||
125 | 240 | 340 | 440 | 540 | 640 | 740 | 840 | |||
130 | 245 | 345 | 445 | 545 | 645 | 745 | 845 | |||
135 | 350 | 450 | 550 | 650 | 750 | 850 | ||||
355 | 455 | 555 | 655 | 755 | 900 | |||||
360 | 460 | 560 | 660 | 760 | 950 | |||||
365 | 465 | 565 | 665 | 765 | 1000 | |||||
370 | 470 | 570 | 670 | 770 | 1050 | |||||
375 | 475 | 575 | 675 | 775 | 1100 | |||||
380 | 480 | 580 | 680 | 780 | 1150 | |||||
385 | 485 | 585 | 685 | 785 | 1200 | |||||
390 | 490 | 590 | 690 | 790 | 1250 | |||||
395 | 495 | 595 | 695 | 795 | 1300 |
Applications:
Deep drawing cookware,
spinning cookware,
road sign,
Building Material,
Insulation,
and so on.
Competitive Advantage:
Good Quality
On-time Delivery
Competitive Price
Efficient After Service
