Utensils 1100 Strongest Aluminum Disk Blanks With Anodizing Corrosion Resistance

China Utensils 1100 Strongest Aluminum Disk Blanks With Anodizing Corrosion Resistance supplier

Large Image :  Utensils 1100 Strongest Aluminum Disk Blanks With Anodizing Corrosion Resistance

Product Details:

Place of Origin: China
Brand Name: Hobe
Certification: ISO/ROHS/SGS

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Pallet or Wooden Case
Delivery Time: 7-35 days
Supply Ability: 1000Ton per Month
Contact Now
Detailed Product Description
Material: Aluminium Alloy Alloy: 1100 1060 1050 3003
Thickness: 0.5mm Above Diameter: More Than 100mm
Surface: Mill Finished Packing: Strong Wooden Case


Utensils 1100 Strongest Aluminum Disk Blanks With Anodizing Corrosion Resistance





Quick Detal:



1. Alloy: 1100, 1050, 1060, 1070, 3003
2. Temper: O, H12, H14
3. Thickness: 0.3mm ~ 10mm
4. Diameter: 20mm - 1300mm
5. Type: Disk, Round sheet, Circle,Disc
6. Min order: 500kgs each size
7. Payment TT or Irrevocable LC at sight



Description:



Aluminum wafers are widely used in electronics, daily chemical,medicine,culture and education,auto parts, electrical appliances, insulation, machinery manufacturing, automotive, aerospace, military industry, mold, construction, printing and other industries.



Kitchen goods such as titanium, pressure cooker, etc. and hardware products such as lampshade, water heater shell, etc. These are the one of the largest aluminum alloy plate and strip processing products.



Alloy: 1000 series 3000 series 5000 series 6000 series

Temper (condition): O H

Material designation: 1060 3003 5052 6061

Thickness: 0.4mm~5.0mm

Diameter: 50mm~1000mm



The properties of aluminum circle for pots, cookware, non-stick aluminium circle (or shaped blanks) make

them ideal for use in a number of markets including the cookware, automotive and lighting industries etc



1. Low anisotropy, which facilitates deep drawing

2. Strong mechanical properties

3. High and homogeneous heat diffusion

4. Ability to be enameled, covered by PTFE (or others), anodized

5. Good reflectivity

6. High strength-to-weight ratio

7. Durability and resistance to corrosion



Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Al
1060 0.25 0.35 0.05 0.03 0.03 --- --- 0.05 0.03 99.6
1050 0.25 0.4 0.05 0.05 0.05 --- --- 0.05 0.03 99.5
1100 0.95 0.05-0.2 0.05 --- --- --- 0.1 --- 99.0
1200 1.0 0.05 0.05 --- --- --- 0.1 0.05 99.0
3003 0.6 0.7 0.05-0.2 1.0-1.5 --- --- --- 0.1 --- remainder



Aluminum Sheet Processing:

Ingot/Master Alloys--->Melting Furnace--->Holding Furnace--->D.C.Caster--->Slab--->Homogenizing--->Hot Rolling Mill--->Cold Rolling Mill--->Punching--->Annealing Furnace--->Finish Inspection--->Packing--->Delivery


Mechanical Properties
TEMPER   THICKNESS(mm)  TENSILE STRENGTH    ELONGATION%     Standard
HO             0.35-10                      60-100                      ≥ 20                    GB/T91-2002
H12            0.5-10                        70-120                      ≥ 4                      GB/T91-2002
H14            0.5-10                        85-120                      ≥ 2                      GB/T91-2002



Aluminum circle Surface Quality


Be free from Oil Stain, Dent, Inclusion, Scratches, Stain, Oxide Discoloration, Breaks, Corrosion, Roll Marks, Dirt Streaks and other defect which will interfere with use.


Aluminum circle Mechanical Property:


Chemical Composite and Mechanical Property could meet the requirements of GB/T, ASTM, ENAW, and JIS Standard


Aluminum circle Packing:


First, plastic cloth with drying agent inside; Second, Pearl Wool; Third, wooden cases with dry agent , fumigation wooden pallets, aluminum surface could cover blue PVC film


Aluminum circle Certificate:


ISO9001:2008, SGS and ROHS (if client request, paid by client), MTC(plant provided), Certificate of Origin(FORM A, FORM E, CO), Bureau Veritas and SGS (if client request, paid by client), CIQS certificate




Specifications:



Section Alloy Characteristics Application
1000 series AA1050 Excellent in forming, welding and
corrosion resistance though
lacking the strength
Kitchen Appliances, Reflector Panel, Traffic Sing,
Decorative Products, Conductive Material,
Construction Material, Electrical Appliances, etc
  AA1060
  AA1070
  AA1100
  AA1200
3000 series AA3003
AA3004
Have slightly higher strength than
AA1100 and excellent in forming,
welding and corrosion resistance
Kitchen Utensils, Interior & Exeterior Materials
for Construuction, etc



Applications:



Deep drawing cookware,

spinning cookware,

road sign,

Building Material,

Insulation,

and so on.



Competitive Advantage:



Though smelting, casting, hot-rolling, cold-rolling, heat-treatment, finishing and other technology,the heavy melting aluminum and an appropriate quality of alloying elements is processed to light nonferrous metal material which has the characters of fine luster, good looking, light weight, poison less and selflessness, and it also has good properties of transmitting electric current and heat, processing and corrosion-resisting applicability.
